12
step 5.
1. Align side of unit with wall stud.
2. Place small hole end of L-bracket against wall/wall stud. Use 1-1/2” screw to secure L-bracket to wall.
3. Use 1/2” screw to secure L-bracket to panel B. L-bracket must be mounted no more than 1 1/2 inches from edge of panel.
warning
All units MUST be fastened to the wall.
panel B
panel A
(H4)
1 in.
MAX
(H3)
wall stud
(H5) x 2
L-bracket
(H3) x 2
L-bracket screw
#10 x 1/2”
(H4) x 2
wall screw
#10 x 1-1/2”
L-bracket must be mounted no
more than 1 1/2 inches from edge
of panel.
1
2
