Target 9-Cube - Page 13

13
1. Attach one set of vertical dividers.
2. Insert long dowels.
3. Attach horizontal divider. Be sure to assemble with all nished edges to front.
4. Push horizontal divider down over dowels. (Holes in horizontal dividers go all the way through.)
5. Secure horizontal divider with two screws through side panel.
6. Attach second set of vertical dividers.
C
D
D
D
D
step 5.
(H1) x 2
assembly screw
#10 x 1-1/2 in. athead
(H4) x 4
long dowel
