9
1. Push 4 short dowels into holes of one xed shelf.
2. Install dowels only into one top/bottom panel (both top/bottom panels are the same.)
3. Top/Bottom panels have six holes on one side with the middle holes going through to the other side.
4. Unnished edges are shaded in light gray.
B
step 1.
(H5) x 4
short dowel
