Target Threshold 009050409 - Page 12

step 06:
12
(Part N)×32
M6*15mm screw
(Part R)×1
allen wrench
A1
A1
A2
A2
B2
B1
B1
B2
G1
G1
G2
G2
G2
G1
Do not completely tighten screws until all screws are in place.
1. Attach the corner bracket1 & 2 (G1 & G2) to the post leg1 & 2 (A1 & A2)
and the connector bar1 & 2 (B1&B2), secure with M6*15mm screws (N)
using the allen wrench (R) .
A2
A1
B2
B2
B1
B1
G1
G2
G1
G2
N
N
