Target Threshold 009050409 - Page 14

step 08:
14
(Part O)×4
M6*35mm screw
H
H
H
H
C
C
B1
B1
Do not completely tighten screws until all screws are in place.
(Part R)×1
allen wrench
1. Attahch another 2 top bars (C) to the end tips (H), secure
with M6*15mm screws (N) and M6*35mm screws (O) using the allen wrench (R).
Make sure all top bars (C) are parallel.
O
H
H
C
B1
B2
N
(Part N)×4
M6*15mm screw
