3
1. Collegare il modulo T-CONNECT per la TAUOPEN 2.0 alla centrale di comando tramite gli appo-
siti cavi. Collegarlo su connettore J4 delle centrali serie Diamond. (g. 1)
N.B: Il modulo T-CONNECT per la TAUOPEN 2.0 funziona solo con centrali con rmware a
partire dalla serie 7.00 (Controllare sull’etichetta del microprocessore)
2. La connessione del modulo T-CONNECT alla rete domestica può avvenire in due modi:
- Via cavo di rete ETHERNET mediante la presa LAN RJ45.
Oppure:
- Congurando il modulo con la rete wi di casa.
ESEMPIO CON RETE WIFI:
- Attendere che sul T-CONNECT il led rosso e il verde lampeggino simultaneamente dopo circa
30 secondi.
- Premere il tasto WPS del router wi di casa (g. 2)
- Subito dopo (se si aspetta troppo tempo il T-CONNECT uscirà dalla procedura), premere il
tastino rosso del modulo T-CONNECT per 1 s, dopodichè i due led si riaccenderanno ssi. Suc-
cessivamente il led verde inizierà a lampeggiare una volta ogni 2 s. per conferma di avvenuta
connessione.
POSSIBILI ERRORI E RIMEDI
ERRORE DESCRIZIONE ERRORE + RIMEDIO
Errore di connessione Se il led verde è acceso e il led rosso lampeggia è un errore di
connessione.
Rimedio: controllare la portata e il segnale del Wi-Fi e ritentare la
connessione (vedi punto 2).
1. Connect the T-CONNECT module for TAUOPEN 2.0 to the control unit using the appropriate
cables. Connect it to connector J4 of the Diamond series control units. (g. 1)
N.B: The T-CONNECT module for TAUOPEN 2.0 works only with control units with rmware
starting from the 7.00 series (Check on the microprocessor label)
2. Connecting the T-CONNECT module to the home network can be done in two ways:
- Via ETHERNET network cable with the RJ45 LAN socket.
Or:
- By conguring the module with the home wi network.
EXAMPLE WITH WIFI NETWORK:
- - Wait for the red and green LEDs to ash simultaneously on the T-CONNECT after about 30
seconds.
- Press the WPS button on the home wi router (g. 2)
- Immediately afterwards (if you wait too long, the T-CONNECT will exit the procedure) press
the red button of the T-CONNECT module for 1 second, after which the two LEDs will turn on
steadily. Subsequently the green led will start ashing once every 2 seconds conrming the
successful connection.
POSSIBLE ERRORS AND REMEDIES
ERROR ERROR DESCRIPTION + REMEDY
Connection error If the green led is on and the red led is ashing it is a connection
error.
Remedy: check the range and the Wi-Fi signal and try the connection
again (see point 2).
