10
A
C
B
A
B
A
B
Rear wheels separately braked (PRO40)
Engage or disengage the brakes on both rear
wheels.
A. Neutral
B. Brake
Central brake (all models except PRO40)
The central brake has three positions; brake, re-
lease, and directional lock. Directional lock means
that the rear wheels are locked in a fixed position,
only allowing the lifter to move straight forward
and straight backwards. This feature keeps the lifter
steady and is helpful when it is transported a rela-
tively long distance.
A. Directional lock
B. Neutral
C. Brake
Always apply brakes when loading and unloading.
Apply brakes to the lifter
There are two different brake options depending on the model of the lifter; rear wheels separately braked or
central brake.
