Taylor C009 Service Manual

2
Introduction
Model C009
090120
Safety
______________________________
We at Taylor are committed to manufacturing safe
operating and serviceable equipment. The many
built-in safety features that are part of all Taylor
equipment are aimed at protecting operators and
trained service technicians alike.
This manual is intended exclusively for
Taylor authorized service personnel.
DO NOT attempt to run the equipment
unless you have been properly trained to do so.
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! Do not operate this
dispenser unless it is properly grounded and all
service panels and access doors are restrained with
screws. Failure to do so can result in severe
personal injury from electrical shock!
S DO NOT attempt any repairs unless the
main power supply to the dispenser has
been disconnected.
S DO NOT operate the dispenser with larger
fuses than specified on the data label.
S Stationary appliances which are not
equipped with a power cord and a plug or
other device to disconnect the appliance
from the power source must have an all-pole
disconnecting device with a contact gap of
at least 3 mm installed in the external
installation.
S Appliances that are permanently connected
to fixed wiring and for which leakage
currents may exceed 10 mA, particularly
when disconnected, not used for long
periods, or during initial installation, shall
have protective devices such as a GFI to
protect against the leakage of current,
installed by authorized personnel to the local
codes.
S Supply cords used with this unit shall be
oil-resistant, sheathed flexible cable, not
lighter than ordinary polychloroprene or
other equivalent synthetic
elastomer-sheathed cord (Code designation
60245 IEC 57) installed with the proper cord
anchorage to relieve conductors from strain,
including twisting, at the terminals and
protect the insulation of the conductors from
abrasion.
Failure to follow these instructions may result in
electrocution or damage to the machine.
Note: This unit is provided with an equipotential
grounding lug that is to be properly attached to
either the rear of the frame or the under side of the
base pan near the entry hole for incoming power, by
the authorized installer. The installation location is
marked by the equipotential bonding symbol (5021
of IEC 60417-1) on both the removable panel and
the equipment's frame, as well as on the diagram.
DO NOT remove any internal operating
parts unless all control switches are in the OFF
position. Failure to follow these instructions may
result in severe personal injury from hazardous
moving parts.
THIS UNIT HAS MANY SHARP EDGES
THAT CAN CAUSE SEVERE INJURIES.
This unit must be installed on a level
surface to avoid the hazard of tipping. Extreme care
should be taken in moving this equipment for any
reason.
Two or more people are required to safely move this
unit. Failure to comply may result in personal injury
or equipment damage.

Taylor C009 Specifications

General

Brand	Taylor
Model	C009
Category	Beverage Dispenser
Language	English
