4
Introduction
Model C009
080508
C009 Specifications
Refrigerated Storage
The C009 concentrate cabinet is refrigerated to
maintain temperature below 41_F(5_C).
Refrigeration Unit
17 oz. R404A refrigerant.
Electrical
Electrical Total Amps
Supplied with
NEMA Cord
115/60/1 Air 2.2 5-15P
This unit may be manufactured with other electrical
characteristics. (For exact electrical information,
always refer to the data label of the unit.)
Water Connection
1/2” SAE male flare at the rear of the dispenser.
Water Supply
The dispenser requires a boosted and chilled water
supply that has been filtered. The supply line should
be capable of providing a two gallon per minute
water flow. The water line is connected at the rear of
the dispenser.
INSTALL POTABLE WATER CONNECTION
WITH ADEQUATE BACK-FLOW
PROTECTION TO COMPLY WITH
APPLICABLE NATIONAL, STATE AND
LOCAL CODES.
Dual Dispense Specifications
DO NOT set the dispenser up for dual
dispense unless all of the following minimum
requirements have been met:
S Dispenser(s) must be connected to a
Multiplex Model 44, Model 50 or Cornelius
Apexx beverage system.
S Water supply line to the dispenser must be
1/2” ID.
S Minimum water flow rate must be no less
than four gallons per minute at any time.
S Booster system must be in proper working
condition.
S Water filters must be in good condition and
changed as needed.
Failure to comply with the minimum requirements
will result in erratic finished product flow rate,
unacceptable product quality, electrical
malfunctions, and a decrease in customer
satisfaction.
Air Cooled
Minimum Air Clearance: 12” (305 mm) at the top
and rear, and 2” (51 mm) on the sides. Minimum air
clearances must be met to assure adequate air flow
for optimum performance.
Dimensions
Width: 11” (279 mm)
Depth: 25” (635 mm)
Height:35” (889 mm)
Approximate Weights
Net: 185 lbs (839 kgs)
Crated: 195 lbs (885 kgs)
This unit is designed and constructed to meet
stringent safety and sanitation requirements for NSF
and other food service regulatory agencies.
Flow Rate
3.0 / 4.5 ounces per second
Handles 2-1 to 10-1 concentrate to water ratio.
