Introduction
5
VGA socket (input)
This socket can be used to connect a computer.
VGA
ANTENNA IN
ANTENNA IN socket (input)
This socket can be used to connect the outside aerial or cable network.
YPBPR component sockets or CMPT IN/ AV IN adapter input AUDIO IN
Y/VIDEO
PB/CB
PR/CR
COMPONENT
IN
These YPBPR sockets can be used to connect a device that has component video
sockets, such as a DVD player. The component sockets can recognize if the device
you're connecting to is Y Pb Pr compatible or Y Cb Cr compatible. The component
sockets provide excellent picture quality because the video is separated into three
separate parts.
Note: 1. T Y and VIDEO share the same socket
T AUDIO IN adapter
and
he .
2. The Y/VIDEO PB/PR socket can be used to connect the attached
Y/VIDEO PB/PR cable with YPBPR component sockets.
3. he socket can be used to connect the attached
AUDIO in adapter cable with audio L & R sockets, be used to obtain sound.
IN adapter
IN adapter
R
L
AUDIO
IN
AV RCA audio + video sockets (input)
Note: T AV IN sockets share the Y and AUDIO IN sockets of
he COMPONENT
IN.
L
AUDIO
VIDEO
AV IN
R
Headphone socket (output)
This socket can be used to connect headphones or stereo earphones.
Warning: excessive sound pressure from earphones and headphones can
cause hearing loss.
HEADPHONE
or
USB socket (input)
These sockets can be used to connect an USB device.
Note: the number of USB sockets on the TV may vary according to TV model.
USB
or
Y/VIDEO PB/PR
IN adapter
AUDIO IN
adapter
CMPT IN/
AV IN
VIDEO
R
L
AV OUT
AUDIO/VIDEO sockets (output) or AV adapter (output) socket
Note: The AV OUT adapter socket can be used to connect the attached AV adapter
cable with VIDEO and AUDIO L & R OUT sockets.
AV OUT
adapter
or
These AV out sockets can be used to connect
The VIDEO OUT socket
p
rovides
a VCR to record programs. You must
leave the TV on the same channel you are recording.
composite video connection.
The HDMI can be used to connect a
blu ray, PC with a compatible video card installed, certain DVD players or a
high-definition compatible digital satellite decoder. This socket p
(High-Definition Multimedia Interface) socket
rovides an
uncompressed digital connection that carries both video and audio data by way of
an integrated mini-plug cable.
HDMI 1 IN
HDMI 2 IN (MHL)
Or
Or
HDMI IN (MHL) or HDMI 1 IN or HDMI 2 IN (MHL) socket (input)
Note: Only HDMI sockets with the MHL identification will support the MHL function,
n
MHL stands for Mobile High-definition Link, and allows you to link a MHL capable
mobile device to the television.
HDMI IN (MHL)
