TCL L42E5300F Service Manual

Factory Test & Alignment Specification For MS63F-LA Series (V0.10)
Page 3 of 18
These chassis are designed for Latin America(LA) markets Ready for IPTV. The main chip is from
Mstar and supports below features matrix:
Class Item MS63F-LA
Inputs
&
Outputs
ATV
( PAL M/PAN N/ NTSC)
CABLE&ANTENNA
DTV
(ISDB-T)
ANTENNA
HDMI
(480i/p, 576i/p, 720p up to 1080i/p, compliant v1.4
with HDCP)
3
VGA
1
VGA/DVI audio
1
CMP
(YPrPb can support from 480i up to 1080p,audio)
1
AV 1
(CVBS ,audio)
1
Side AV
(CVBS,audio)
1
AV OU T
1
USB thumb drive
2
- Picture,Video,Audio Playback
- Hub, Mouse, Keyboard rd
Headphone output
1
SPDIF output
Optical
Functions
OAD
•
WIFI Ready
USB Dongle accessory
(IEEE 802.11 b/g/n)
DIVX
•
DLNA (DMP)
•
Internet
Opera
3D (auto, top & bottom, side by side, frame
sequencing, …)
1920x2205@24Hz (1920x1080p x2)
1280x1470@50Hz (1280x720p x2)
1280x1470@60Hz (1280x720p x2)
Passive Glasses
Audio Return Channel (ARC)
•
Serial connector
N/A
Others
VGA connector
P508
I2C connector of MEMC module
N/A
Main SW Serial NAND Flash
BIN image
U301
V8-6328L01-LF1Rxxx
IC Details
&
Position
Main EEPROM
U302
VGA connector pinout:
VGA/P508 Pin4:RXD VGA Pin11:TXD
