Page 9 of 27
PCMCIA
CI CAM card adaptor
Conax, Irdeto, Viaccess, …
SCART/AV IN via adaptor on MT31B/T
(CVBS & RGB & S-VIDEO)
Chroma/Fluke generator
PAL Half Color & Gray bars 720x576
Half Color & Gray bars
SCART/AV OUT via adaptor on
MT31B/T
(CVBS & Audio out)
Monitor
Suitable channel
PC
(VGA)
Chroma/QuantumData
generator
WXGA - 1368x768@60Hz
Half Color & Gray bars
CMP via mini jack adaptor on MT31B/T
(YPrPb & Audio)
Chroma/QuantumData
generator
1920x1080i@60Hz
Half Color & Gray bars
HDMI
Video & Audio with beyond
HDMI 1.4a and HDCP
compliant DVD/BD player
2D - Movie 1920x1080@p24Hz
MHL
up to 720p
ARC
PCM or Dolby D+
CEC
One Touch Play/ Routing Control/ Sys Standby/
Sys Info/ Give Device Power Status/ Pass
Through/ System Audio Control/
Audio Return Channel
RJ-45
IP Return
DHCP Server ICMP packets echo request
Headphone
RF signal
Suitable channel
Loud Speakers / Enclosures
RF signal
Suitable channel
Picture/Video formats and Audio tones can be changed by the factory according to their own standard and
broadcasted signals (ie: 1KHz & 3KHz, sweep, …).
1.6. AD Calibration Test
N/A
As SoC as built-in A/D self-calibration mechanism, there’s not any ADC to perform.
1.7. DDC & EDID & T-Link Test
The E-EDID data structures are according to VESA Enhanced EDID 1.4a (and EIA/CEA-861B for HDMI)..
All VGA and HDMI structures have their own BIN profile which are part of firmware and uploaded at power-on.
For EDID check, it’s recommended to check whether the correct EDID is uploaded by checking corresponding
EDID NVM Checksum or read them out to check bit by bit if it is in line with the released EDID bin file.
1.8. HDCP Upgrade and Test
See Appendix ⑸ “How to upgrade HDCP KEY by UART”
For HDCP compliancy, it’s needed to check whether the HDCP key has been well set by connecting suitable
generator signal.
