Item No. Description Quantity Req. Designator Remarks
08-00029E-CR7 ASS'Y - CRT BD 1
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D501
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 L501 FOR "+" TO P1/P503
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D502
11-A562TM-0BX TRANSISTOR 2SA562TM-0 1 Q507
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q502
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q504
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q506
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q501
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q503
11-SC4544-0AX TRANSISTOR 2SC4544 1 Q505
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R515
18-CB0272-JNX RES. C.F. 2.7k OHM 1/6W +/-5% 1 R514
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R501
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R505
18-CB0561-JNX RES. C.F. 560 OHM 1/6W +/-5% 1 R510
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R502
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R506
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R509
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R522
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R503
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R508
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R513
18-CB0681-JNX RES. C.F. 680 OHM 1/6W +/-5% 1 R511
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R519
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R520
18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R521
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R516
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R517
18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R518
25-BCB471-M1X CAP. ELEC 470 UF 16V +/-20% 1 C506
25-BLA100-M1X CAP. ELEC 10 UF 250V +/-20% 1 C504
26-AMK102-KRX CAP. CER 1000 pF 2KV +/-10% R 1 C505
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C508
26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C509
9
