−5−
EXPLODED VIEW LIST
REF.NO. PARTSNO. DESCRIPTION REMARKS
1 9A06677900 BADGE KGB1A047
2 9A09287800 HOUSING,VOLUME KGK1A071C11
3 9A09287700 VOLUMEKNOBASSY KGK1A070ZA
4 9A09288300 WINDOW,FIP KGU1A264A8Z
5 9A06228400 VOLUMECAPASSY(C) KGX1A218ZA
6 9A09276400 KNOB,ROTARY KBN1A146M9K79
7 9A09287500 BAR,SIDE KGK1A069C11
8 9A09290300 PANEL,AL[J,US,C] KKM1A114ZC11
9A09297800 PANEL,AL[E,UK] KKM2A114YC11
9 9A09287400 DOOR,AL KGK1A067ZC11
10 9A09288200 DOOR,MOLD KGR1A235M9K79
11 9A09288000 BAR,ORNAMENT(L) KGR1A233MBC22
12 9A09288100 BAR,ORNAMENT(R) KGR1A234MBC22
13 9A08792000 WINDOW,SENSOR KGU1A245A10
14 9A09290900 DOOR,LOCK KMH1A133
15 9A09287900 INDICATOR,FUNCTION KGL1A193
16 9A09288500 PANEL,MOLD KGW1A316M9ZK64
17 9A09276900 DAMPERGEARASSY KDG1A006W
18 9A09293900 DOORSPRING KUS2A127
19 9A09282900 SPRING,OPEN KUS1A126
20 9A09286500 KNOB,OPEN KBC1A136M9K64
21 9A09286700 KNOB,DTS KBT1A772M9K64
22 9A09286800 KNOB,TUNING KBT1A773M9K64
23 9A07301300 INDICATOR,POWER KGL2A120
24 9A09297600 KNOB,POWER[E,UK] KBC1A135M9K64
25 9A07301200 KNOB,POWER KBT2A387ZK64
26 9A09293300 CHASSIS,BOTTOM KUA1A200
27 9A06315500 FOOT KKL1A047ZK63
28 9A06229300 CUSHION,FOOT KHG1A039Z
29 9A06229100 MOUNT,PCB KHE1A023
30 9A01375500 PCBHOLDER KHE170
31 9A09290100 CABINET,TOP KKC1B122S21
32 9A09290700 BRACKET,HEATSINK KMD1A448
33 9A09291200 HEATSINK(F) KMY1A181
34 9A09291400 HEATSINK(R) KMY1A182
35 9A09290800 SUPPORT,HEATSINK KMH1A119
36 9A09290200 PANEL,REAR[J] KKF1A223WK59
9A09290210 PANEL,REAR[US,C] KKF1A223ZK59
9A09290220 PANEL,REAR[E,UK] KKF2A223YK59
37£ 9A06754900 BUSHING,ACCORD KHR1A028
40£ 9A08144000 CORD,POWER[J] BJA2J049Z
£ 9A08043100 CORD,POWER[US,C] BJA523FBY
£ 9A08032300 CORD,POWER[E] BJA2B044Z
£ 9A09267600 CORD,POWER[UK] BJA2E045Z
41 9A09275300 TUNERMODULE[J] BNVTFCE1J101A
9A09306200 TUNERMODULE[US,C] BNVTFCE1U116A
9A09296900 TUNERMODULE[E,UK] BNVTFCE1E320A
42 9A09275100 FAN,MOTOR BDMKD1206PTS3
43£ 9A09290400 TRANSFORMER,POWER[J] KLT5V029ZJ
£ 9A09290410 TRANSFORMER,POWER[US,C] KLT5V029ZU
£ 9A09290420 TRANSFORMER,POWER[E,UK] KLT5V029ZE
F903,F904£ 9A07044800 FUSE KBA2C8000TLU
F905£ 9A08888400 FUSE[J] KBA2C8000TLJ
F905£ 9A07044800 FUSE[US,C] KBA2C8000TLU
F905£ 9A06784300 FUSE[E,UK] KBA2C6300TLE
