TECHNICAL BULLETIN 10
th
Sep 1999
Page 1 of 1
MODEL:
EU-34T (AK20 CHASSIS)
PROBLEM:
“White Dot Noise” pattern visible on low RF signal input.
File: EU-34T (Whitedot).doc / EU-34T (Whitedot).pdf
White dot noise pattern occurs when signal RF input is too low. This modification will improve the signal/noise
vastly.
Instructions:
1. Remove C820 (Ceramic Cap 270pF 1KV)
2. Insert (Ceramic Cap 470pF 1KV) into location C820
3. Add a 0.22nF 630V capacitor in parallel with D806.
Regards,
Fabian Lubanovic
TEAC Australia Pty Ltd.
