Teac GF-650 - Page 13

POWER MAIN PCB ASSY (CD MECHAN. ASSY)
REF. NO
REMARKS
PARTS NO.
48-01R00A200223
POWER MAIN PCB ASSY (CD MECHAN. ASSY)
DESCRIPTION
U701
U504
U502
U201
Q801,802
U301
Q803
IC - M5237ML-600C
IC - MSM5416258B
SMD ZENER DIODE 5.1V
16-M5237ML00021
16-M54160000021
12-011510320521
16-AK5353VT0021
IC - AK5353VT
IC - AK8567
16-AK8567000021
SMD TR - 2SC4555-7
11-2SC455570021
IC - BA5960FS
16-BA5960FS0021
11-DTA124EK0021
SMD TR - DTA124EKA
12-011560320511
SMD ZENER DIODE 5.6V
05-01RA00200020
POWER MAIN PCB
U101
U605
16-BH3802KV0021
IC - BH3802KV-E2
16-BR9080AF0021
IC - BR9080AF-W-E2
16-EN29F0020021
IC - EN29F002ANT
U602
GF-650
U501
16-LC8958700021
IC - LC89587-UKI
SMD TR - 2SB1132
D601
11-2SB113200021
Q301,700
D609
U205
16-AD8402AR0021
IC - AD8402AR10
D500
12-DAN217000021
DIODE - DAN217
12
U207,208
16-NJM3404A0021
IC - NJM3404AV
U604
16-PST597EN0021
IC - PST597ENR
U206
16-TC4W53FU0021
IC -TCW53FU
U505
16-TC74VHC00021
IC - TC74VHC08FT
U507
16-TC74VHC10021
IC - TC74VHC14FT
U506
16-TC74VHC30021
IC - TC74VHC32FT
U601
16-TMP95C260021
IC - TMP95C265FG
X501
31-018338600115
V/CHIP CRYSTAL 33.8688MHZ
X601
31-048225701415
CHIP RESONATOR 22.57MHZ
SW300,301
41-061120100020
LEAF SWITCH
CN201
43-011500234120
SMD WAFER 0.5MM 34PIN
CN601
43-012100190530
SMD FFC WAFER 1MM 9PIN
CN501
43-012100217530
SMD FFC WAFER 1MM 17PIN
CN602
43-021800220520
SMD WAFER 0.8MM 20PIN
CN301
43-022150120520
SMD WAFER 1.5MM 2PIN
CN503
43-022150160520
SMD WAFER 1.5MM 6PIN
CN302
43-022150190520
SMD WAFER 1.5MM 9PIN
CN801 43-022200130520
SMD WAFER 2MM 3PIN
CN502
43-022200140520
SMD WAFER 2MM 4PIN
CN701
43-022200160520
SMD WAFER 2MM 6PIN
F701,702
46-125200200010
SMT FUSE 6125T-2A
!
