Teac GF-650 - Page 15

DISPLAY PCB ASSY
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
05-04GF35000010
48-04GF35000222
DISPLAY PCB
05-04GF35000000
DISPLAY PCB ASSY [T/C,JIS]
DISPLAY PCB ASSY [E]
Q501
11-DTA124ES0025
TR - DTA124ES
D503-506
13-011200022020
LED LAMP 2x5x7mm (WHITE)
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
05-09GF65000000
HP PCB ASSY
HP PCB ASSY
HP PCB
L4,8,9
38-013100050120
AXIAL INDUCTOR 10UH #EC-24
14
GF-650
D507
13-011292121020
LED LAMP (RED)
D502
13-011306622020
LED LAMP 3mm (BLUE)
LCD501
13-05GF35000021
LCD DISPLAY #SDT-DA870
U501
16-LC877C32C021
IC - LC877C32C
U503
16-PST600D00021
IC - PST600D
U502
17-05FM60380011
OPTIC SENSER #FM-6038TM2-5A
S500,501
22-501200000820
ROTARY ENCODER E1211A3AV1NG0000
X501
31-047450000020
CERAMIC RESONATOR 4.5MHZ
SW511-517,
SW521-526
41-150010030020
TACT SW 6x6mm
CN502
43-012100190530
SMD FFC WAFER 1MM 9PIN
CN504
43-022200160120
WAFER 2MM 6PIN
48-09GF35000120
43-431360006020
PH 3.6MM JY353507001
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
05-09GF65000100
AUX PCB ASSY
AUX PCB ASSY
AUX PCB
L1-6
38-013100050220
AXIAL INDUCTOR 10UH #EC-36
48-09GF35000220
43-451400002020
RCA JACK 4PIN
JK1
PHONE J
