Teac GF-650 - Page 8

REF. NO
EXPLODED VIEW-1
PARTS NO.
DESCRIPTION
REMARKS
8
GF-650
1-51
1-52
1-53
1-54
1-55
1-56
1-58
1-59
1-60
1-61
1-62
1-63
1-64
1-65
66-140530180121
1-48
1-49
1-50
1-57
1-66
1-67
1-68
66-120830220321
66-120226150321
MACHINE SCREW MS/BH 2.6x5mm
61-95T060800020
SPRING DIAL
66-120240222321
66-120230214121
66-140230214321
66-140230212121
!
66-140830210321
66-140230210121
66-140230180121
LOOSE LEAF
61-57GF35000020
66-140330210321
66-140226180321
66-140230210321
66-140230214121
66-120230180321
66-120330160321
66-120526140321
66-120230210321
61-57GF65000020
WOODEN BOX OPEN/CLOSE SHAFT
1-69
66-140330180321
MACHINE SCREW MS/BH 3x8mm
MACHINE SCREW MS/BH 3x10mm
MACHINE SCREW MS/BH 3x14mm (BLK)
MACHINE SCREW MS/BH 4x22mm
MACHINE SCREW MS/PH 3x6mm
MACHINE SCREW MS/KH 2.6x4mm
MACHINE SCREW MS/WH 3x20mm
SELF-TAPPING SCREW TA/BH 2.6x8mm
SELF-TAPPING SCREW TA/BH 3x8mm (BLK)
SELF-TAPPING SCREW TA/BH 3x10mm (BLK)
SELF-TAPPING SCREW TA/BH 3x10mm
SELF-TAPPING SCREW TA/BH 3x12mm (BLK)
SELF-TAPPING SCREW TA/BH 3x14mm (BLK)
SELF-TAPPING SCREW TA/BH 3x14mm
SELF-TAPPING SCREW TA/PH 3x8mm
SELF-TAPPING SCREW TA/PH 3x10mm
SELF-TAPPING SCREW TA/KH 3x8mm (BLK)
SELF-TAPPING SCREW TA/WH 3x10mm
1-70
66-141430210321
SELF-TAPPING SCREW TA/WH 3x10mm
1-71
66-150330160321
SELF-TAPPING SCREW TB/PH 3x6mm
1-72
66-150830180121
SELF-TAPPING SCREW TB/WH 3x8mm (BLK)
1-73
66-170230160321
HARDEN SCREW TT/BH 3x6mm
1-74
67-021300000120
NUT+WASHER DIA M3MM
1-75
67-021400000020
NUT M4MM
1-76
68-112403101000
METAL WASHER 4x10x1mm
1-77
68-412400000000
RING “E” TYPE 4mm
1-78
02-20GF35000000
CD MECHANISM ASSY
1-79
18-205GF3500120
H/TRANSFORMER EI66 230V [E]
18-203GF3500120
H/TRANSFORMER EI66 120V [T/C]
H/TRANSFORMER EI66 100V [JIS]
18-201GF3500120
1-80
19-021093100220
SPEAKER 3” 10W - 4 OHM
1-38
1-39
58-71GF65000020
WOODEN PLATE 230x292x3mm
58-71GF35000020
WOODEN BOARD
58-71GF35000120
WOODEN TOP COVER
58-73GF35000020
WOODEN BOX
61-11GF35000020
CD MACHINE BRACKET (L)
61-11GF35000120
CD MACHINE BRACKET (R)
1-40
1-41
1-42
1-43
1-44
61-11GF35000221
WOODEN BRACKET
1-45
61-11SN11600021
PVC BRACKET
1-46
61-22SG19000020
BUSHING MOUNTING PLATE
1-47
61-25SCD6600020
CONTACT PLATE
!
!
