Teac MC-DX20 - CD(MP3) PCB ASSY - TOP; CD(MP3) PCB ASSY - BOTTOM

CD(MP3) PCB ASSY - TOP
REF. NO
DESCRIPTION
PARTS NO.
05-30DX01510100
CD(MP3) PCB ASSY - MC-DX20 [E,UK]
CD(MP3) PCB ASSY - MC-DX20 [HK,SIN]
05-30DX01510001
CD(MP3) PCB ASSY - MC-DX20 [AUS]
IC2
16-S1L9226X0021
IC - S1L9226X01
IC4
16-S5L927900021
IC - S5L9279X01
IC7
16-S3P825A00421
IC - S3P825A
IC9
16-KA9259D00021
IC - KA9259D
CD(MP3) PCB ASSY - BOTTOM
REF. NO
DESCRIPTION
PARTS NO.
D7
12-1N5819000021
RECTIFIER DIODE 1N5819
D1-5,9,10,55,56,
D66,67,71-73,78
12-1N4148000021
DIODE 1N4148
D6,8,12
12-011390320121
ZENER DIODE 3.9V
Q1,7,9,10
11-9015C0000021
TR - 9015C
Q2,3,4,8
11-9014C0000021
TR - 9014C
Q5
11-8550C0000021
TR - 8550C
X1
31-018169302220
CRYSTAL 16.9344MHZ.
X2
31-015320003310
CRYSTAL 32.768KHZ
X3
31-017800002120
CRYSTAL 8.000MHZ
L1,2,3
38-013100050020
AXIAL INDUCTOR 10UH
!
CN2
43-022100216020
F.F.C WAFER 1MM 16 PIN
CN3
43-012150160320
WAFER 1.5MM 6 PIN
CN4
43-022200120120
WAFER 2MM 2 PIN
CN5,9
43-022200130120
WAFER 2MM 3 PIN
C56
26-017220650121
E.CAP 2200UF/10V
!
IC8
IC - M12L16161A
05-30DX01510110
16-M12L16160021
05-30DX01500011
REMARKS
13
MC-DX15/20
48-30DX01500322
CD(MP3) PCB [E,UK,AUS,HK,HK]
48-30DX01501321
CD(MP3) PCB - MC-DX15
CD(MP3) PCB ASSY - MC-DX15
REMARKS
12-1N4148000021
DIODE 1N4148 [E,UK]
D11,62
