Teac MC-DX20 - SUBWOOFER POWER PCB ASSY; RCA;D-S JACK PCB ASSY

REF. NO
PARTS NO.
DESCRIPTION
SUBWOOFER POWER PCB ASSY
05-07DX01500010
SUBWOOFER POWER PCB ASSY [E,UK,HK,SIN]
48-07DX01500122
SUBWOOFER POWER PCB
CN1
43-012250130120
WAFER 2.5MM 3 PIN
CN2
43-012200190120
WAFER 2MM 9 PIN
CN4
43-012250150120
WAFER 2.5MM 5 PIN
CN5
43-012250140120
WAFER 2.5MM 4 PIN
CN6
43-012250120120
WAFER 2.5MM 2 PIN
C701
26-017470850121
E.CAP - 4700UF/25V
C718,719
26-017100750121
E.CAP - 1000UF/16V
C406
26-017470950111
E.CAP - 4700UF/35V
D401-404
12-1N5401000021
RECTIFIER DIODE 1N5401
D701-704
12-RL2020000021
RECTIFIER DIODE RL-202
D705,707
12-1N4148000021
DIODE 1N4148
D301,706
12-1N4001000021
RECTIFIER DIODE 1N4001
FU2,3
FU4
Q301,709
11-9014C0000021
TR - 9014C
Q707,708
11-2SD1936T0021
TR - 2SD1936T
U1
16-TA8216H00021
IC - TA8216H
U2
16-BA4558N00021
IC - BA4558N
U3
16-BA5417000021
IC - BA5417
ZD1,2
12-011910320121
ZENER DIODE 9.1V
!
!
!
!
!
!
!
05-07DX01500001
SUBWOOFER POWER PCB ASSY [AUS]
46-055350300010
GLASS FUSE 3.5A/250V
46-055400300010
GLASS FUSE T4A/250V
REMARKS
15
MC-DX15/20
CN3
43-012200130120
WAFER 2MM 3PIN
REF. NO
PARTS NO.
DESCRIPTION
RCA/D-S JACK PCB ASSY
05-08DX01500010
RCA/D-S JACK PCB ASSY
48-08DX01500220
RCA/D-S PCB
RCA801
43-451200006120
RCA JACK 2PIN
REMARKS
L801-804
CHOKE COIL 10UH
CN801
43-462103003320
D-S TERMINAL #DSW-31
43-462103003320
