Teac MC-DX20 - KEY; DISPLAY PCB ASSY; STANDBY PCB ASSY; HP;AUX JACK PCB ASSY; OPEN SW PCB ASSY

KEY / DISPLAY PCB ASSY
REF. NO
PARTS NO.
KEY/DISPLAY PCB ASSY- MC-DX15, MC-DX20 [HK,SIN]
05-05DX01500000
DESCRIPTION
KEY/DISPLAY PCB
48-05DX01500120
Q707
11-9015C0000021
TR - 9015C
LED2,4
13-011506022120
LED D5MM - BLUE
SW1-13
41-150010030020
TACH SW 6x6mm 4 LEGS
REM
17-05FM60380011
OPTIC SENSOR FM-6038TM2-5A
LED1,3
13-011300022020
LED D3MM - WHITE
LCD
13-05DX01500020
LCD DISPLAY SDH-M2112-TN-1
REMARKS
17
MC-DX15/20
KEY/DISPLAY PCB ASSY - MC-DX20 [E,UK]
05-05DX01500020
KEY/DISPLAY PCB ASSY - MC-DX20 [AUS]
05-05DX01500010
REF. NO
PARTS NO.
DESCRIPTION
HP/AUX JACK PCB ASSY
05-09DX01500000
HP/AUX PCB ASSY [AUS]
48-09DX01500120
HP/AUX PCB
L401,402,403,405
38-013100050220
AXIAL INDUCTOR 10UH
AUX
43-451200012020
RCA JACK 2PIN
HEADPHONE
43-433160004020
PHONE JACK 3.5MM
REMARKS
REF. NO
PARTS NO.
DESCRIPTION
REMARKS
OPEN SW PCB ASSY
48-23DX01500220
OPEN SW PCB ASSY
41-071200000020
SERIES MICRO SWITCH SD-002
REF. NO
PARTS NO.
DESCRIPTION
REMARKS
41-071200000020
SERIES MICRO SWITCH SD-002
CLOSE SW PCB ASSY
48-23DX0150022A
CLOSE SW PCB ASSY
05-09DX01500010
HP/AUX PCB ASSY [E,UK,HK,SIN]
STANDBY PCB ASSY
REF. NO
PARTS NO.
STANDBY PCB ASSY - MC-DX20 [E,UK,HK,SIN]
05-03DX01500000
DESCRIPTION
WAFER 3PIN P=2MM
43-012200130120
Q303
16-LM78L0500121
IC - LM78L05
Q302
11-9014C0000021
TR - 9014C
FU1
46-074100300020
SUBMINIATURE FUSE 100MA/250V
REMARKS
STANDBY PCB
48-03DX01500120
DIODE - 1N4001
12-1N4001000021
D309-315
CN301
RL301
46-50MC23000000
RELAY ME-7-009
!
