Teac SR-L35 - Page 14

CD PCB ASSY
REF. NO
REMARKS
PARTS NO.
DESCRIPTION
100-SR352020
CD PCB ASSY
062-SRL35001
CD PCB
C230
072-30220101
CE 2200UF/10V
IC10
075-00209001
IC - TA2092A
IC11
075-00215301
IC - TA2153FN
IC14
075-00729111
IC - TA7291S
IC9
075-094A0931
IC - TC94A09F-202
Q203,204
076-00C94500
TR - 2SC945
Q202
076-00A73300
TR - 2SA733
Q201
076-00B54400
TR - 2SB544F
D201-207
077-00414801
DIODE 1N4148
L9,10
095-00100001
INDUCTOR 10UH
XT2
093-A0750002
CRYSTAL 75KHZ
XT3
093-11693440
CRYSTAL 16.9344MHZ
CN24
082-20240100
CONNECTOR 2P P=2.5MM
CN20,22
082-20300100
CONNECTOR 3P P=2MM
CN10
082-10600100
CONNECTOR 6P P=2MM
CN5
082-21350300
FPC CONNECTOR 13P P=1.25MM
CN25
082-21430300
FPC CONNECTOR 14P P=1MM
CN12
082-21530300
FPC CONNECTOR 15P P=1MM
CN18
082-31630100
FPC CONNECTOR 16P P=1MM
L11
052-SRL50010
HORIZONTAL FERRITE CORE
!
CONNECTOR 6P P=1.5MM
082-20660100
CN17
SR-L35
14
