Teac SR-L35 - Page 18

SR-L35
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
062-SRL35003
POWER LED PCB ASSY
100-SR352070
POWER LED PCB ASSY
LED01
094-06030502
BLUE LED 5MM
POWER LED PCB
DC JACK PCB ASSY
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
100-SR352080
DC JACK PCB ASSY
062-SRL35003
DC JACK PCB
CN8
082-10340100
CONNECTOR 3P P=2.5MM
JK1
064-20110102
DC JACK TD0202-20
CN1
082-10540100
CONNECTOR 5P P=2.5MM
JK2
064-35020101
HEAD PHONE JACK TE-03506S-11
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
062-SRL35003
PHONE JACK PCB ASSY
100-SR352090
PHONE JACK PCB ASSY
PHONE JACK PCB
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
AUX JACK PCB ASSY
100-SR352100
AUX JACK PCB ASSY
062-SRL35005
AUX JACK PCB
JK3
SW023
086-SRL35020
AUX JACK 2P TR-0209RW
063-SRL35080
TACT SWITCH TS-01L8B
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
100-SR352110
LEAF SWITCH
063-SRL35400
CD DOOR SW PCB ASSY
L12
095-10270001
INDUCTOR 270UH
REF. NO
DESCRIPTION
REMARKS
PARTS NO.
DC MOTOR PCB ASSY
100-SR352120
CD MOTOR PCB ASSY
062-SRL35003
CN21
082-10300100
CONNECTOR 3P P=2MM
DC MOTOR PCB ASSY
CD DOOR SW PCB ASSY
SW19
