Team C Patron - Page 7

5
7
Diff
Diff.
3
T02100 5x10x4 Ball Bearing
5x10x4 Kugellager
……………4
86000 5.1x8x0.2 Washer
5.1x8x0.2 Scheibe
………………4
……………12
T04040 M2.5x6 Screw
M2.5x6 Schraube
TS4051/TS4052 M3x8 Screw
M3x8 Schraube
……………2
T04040 M2.5x6
TS4051
M3x8
T02100 5x10x4
Center Front
Mitte vorne
Center Rear
Mitte hinten
6
x2
T04040 M2.5x6
x1
Center Connecting Cup F
Mittel Mitnehmer vorne
TS4051
Center connecting Cup-R
Mittel Mitnehmer hinten
TS4052
86000
5.1x8x0.2
86000
5.1x8x0.2
T02100 5x10x4
16T gear
16T Zahnrad
T04041
16T gear
16T Zahnrad
T04041
TS4052
M3x8
TR4059 M3x8 Screw
M3x8 Schraube
………4
TR4059 M3x10 Screw
M3x10 Schraube
………6
TR4002
Front Gear-box-cover
Vordere Getriebeabdeckung
TR4003
Rear Gear-box-cover
Hintere Getriebeabdeckung
TR4059 M3x10
TR4059 M3x8
TR4059 M3x8
TR4059 M3x8
TR4059 M3x10
TR4059 M3x10
x2
Assemble as many times as specified
In angegebener Anzahl fertigen
Apply threadlocker(screw cement)
Schraubensicherungslack verwenden
Screw
Cement
Screw
Cement
Screw
Cement
Diff
Diff.
30000#
Bag-A
Bag-A
Bag-A
30000# for Front
10000# for Rear
30000# Vorne
10000# Hinten
Center Connecting Cup
Mitnehmer Mitte
