TECATOR Soxtec System - UNPACKING AND CHECKING

UNPACKING AND CHECKING
Unpack the SOXTEC SYSTEM and its accessories with care.
Remove all packing material. Use the packing list in this ma-
nual or the one you find packed together with the unit, and
check that you have received all parts. If any part is missing,
contact your Tecator representative.
PACKING LIST
r
r
Part no.
1040-001
1040-002
1040-003
1040-011
1041-011
Quant.
1
1
1
2
1
1
1
3
1
2
1
1
3
3
1
1
1
3
1
1
3
1
2
1
1
2
1
1
2
1
Fig. pos.
A 1
2
3
4
5
6
7
8
9
10
11
12
12
A 13
14
15
16
12
12
A:1 1
2
3
A:2 1
2
3
4
Description
Soxtec System M6 comprising:
1040-011 Extraction Unit
1041-011 Service Unit
1000-1540 Manual
Soxtec System M12 comprising:
1040-011 Extraction Unit
1041-011 Service Unit
1000-1461 AssemblyKit
1000-1540 Manual
Soxtec System M18 comprising:
1040-011 Extraction Unit
1041-011 Service Unit
1000-1461 AssemblyKit
1000-1540 Manual
Extraction Unit, complete, comprising:
1040-012 Extraction Unit
1000-1462 Extraction Cups (set of 6)
1000-1431 CupHolder
1000-1464 Thimble support (set of 7)
1000-1080 Holder for thimble support
1522-0018 Thimbles(setof25)
1000-1466 Thimble Adapters (set of 6)
1000-1467 Thimble Handler
1529-0007 Tongs for extraction cups
1000-1473 Thimble Stand
1000-1476 Tubing (0 8/11 mm)
1569-0010 Plastic strips
1000-1469 Spare Part Kit A
Service Unit, complete, comprising:
1041-012 Service Unit
(208—240 V, 50/60 Hz)
1000-1432 Tubing for hot water
1000-1477 Tubing for air
1527-0019 Lubricatingoii
1569-0009 Plastic strips
1000-1468 Spare Part Kit B
Spare Part Kit A comprising:
1000-1420 Sealing membranes (set of 6)
1000-1424 Cylindricseals(setof 6)
1569-0010 Plastic strips (set of 10)
Spare Part Kit B comprising:
1577-0028 Shaft sealing (water pump)
1577-0014 Membrane(pressurepump)
1542-0026 Gasket (set of 4 for
hot water tubing)
1569-0009 Plastic strips (set of 4)
