Operator'sguide
5.CHECKINGCORRECTOPERATION
Beforeusemakesurethat:1 2.
3. 4 5.
6.
7.
8.
6.DEFROSTING
1. 2.
7.INSTALLATION
1. 2
8.DISPLAY
9.TEMPERATURESETTING
1. 2.
3.
4.
N.B.
DRINK361:
10.LOW-TEMPERATURE ALARM
1.
2.
Maximumtemperaturealarm
(DRINK380+WINECONSOLLE)
HOWTOSEETHESETPOINT
HOWTOCHANGETHESETPOINT
HOWTOSTART A MANUAL DEFROST
DRINK361:
.theplugisconnected; thermostatshowsthedesiredtemperaturefor
thegoodstobestored; thelightsareturnedon; .doorisfirmlyclosed; applianceisnotexposedto
directsunlightortopowerfullamps; ambienttemperaturedoesnotexceed+30°Cwith55%R.H.;
thereissufficientventilationforthemotorcompartment;thereisaclearanceofatleast10cmbetween
thewallandtherearsideoftheappliance; thecabinetissuitablyfilledandshelvesarenotoverloaded.
Defrostingisautomatic. Condensationwateriscollectedinabasinabovethecompressor,whereit
evaporates.
Installtheapplianceinadryenvironment,awayfromdirectsunlight. .Usethefrontfeettolevelthe
machine
Thedisplayshowstheactualtemperatureatthetoporbottomofthecabinet. Toswitchthedisplay
betweenthetopandbottomsections,short-pressthetopandbottombuttonsrespectively. The
temperaturedisplayhasabuilt-infilterthatsimulatestheactualtemperatureinthebottles.
Thetemperatureissetusingthetwobuttonsonthecontrolpanel. (SET 1)Theupperbuttonisused
tosetthetemperatureatthetopofthecabinet;(SET 2)thelowerbuttonisusedtosetthetemperatureat
thebottom. Deactivatethechildprooflockbypressingthebuttonfot3seconds,whenthedisplay
startsflashing,thetemperaturecanbesetbyscrollingthesettingbetween22and5°C. Whenthe
desiredsettingisdisplayed,releasethebuttonfor3seconds,thesettingwillthenbestoredandthe
childprooflockreactived. Thebottomsectioncannotbegivenahighertemperaturesettingthanthe
topsection(seefig.2). Pushthebutton(ARROW)toincreasesetpointandtodecreasethe
setpoint.InECOmodethesetpointishigherthaninservingmode.ECOmodeisswitchedON/OFFby
pushingtheECObuttonECOmodeisalsoswitchedONwhenthedoorhasnotbeenopenedfor3hours,
andswitchedOFFagainatthefirstdooropening.
Ifthetemperaturehasbeenbelow2°Cformorethan1hour,thedisplayflashesandLo/actual
temperaturearealternatelyshown. Two-zonesettingforservingtemperature Typicalserving
temperaturesettingsforthetopandbottomsectionsare16°Cand6°Crespectively.Withthesesettings,
asuitabletemperaturegradientwillbeachievedinthecabinetforthestorageofvarioustypesofwine
distribuitedfromtoptobottomasfollows:heavyredwines(+16to+19°C),roséandlightredwines(+12
to+16°C),whitewine(+10to+12°C),champagneandsparklingwines(+6to+8°C). Forlong-term
winestorage,thetopandbottomsectionsshouldbothbesetat12°C.
Thealarmsoundswhenthetemperatureofthetopsensorismorethan2°Cabovethesetpoint.
Thebuzzerisactivatedatanintervalofapprox.1secondforadurationofapprox.0.5second.
Thealarmsoundstopswhenoneofthekeysispressedorwhenthetemperatureis2°Cabovetheset
pointagain.
ThetemperatureandHtA(hightemperaturealarm)aredisplayedalternately.
Thealarmlimithastobeexceededfor60minutesbeforethealarmisactivated –exceptatstart-upwhere
thedelayis90minutes.
Thealarmsoundswhenthetemperatureofthetopsensorismorethan5°Cabovethesetpoint.
Thebuzzerisactivatedatanintervalofapprox.1secondforadurationofapprox.0.5second.
Thealarmsoundstopswhenoneofthekeysispressedorwhenthetemperatureis5°Cabovetheset
pointagain.
ThetemperatureandHtA(hightemperaturealarm)aredisplayedalternately.
Thealarmlimithastobeexceededfor60minutesbeforethealarmisactivated –exceptatstart-upwhere
thedelayis90minutes.
1.PushandimmediatelyreleasetheSET key,thesetpointwillbeshowed;
2.PushandimmediatelyreleasetheSET keyorwaitabout5storeturntonormalvisualisation.
1.PushtheSET keyformorethan2secondstochangetheSetpointvalue;
2. Thevalueofthesetpointwillbedisplayedandthe “°C” or “°F” LEDstartsblinking;
3. TochangetheSetvaluepushtheorarrows.
4. TomemorisethenewsetpointvaluepushtheSET keyagainorwait10s.
PushtheDEFkeyformorethan2secondsandamanualdefrostwillstart
Ifthereisaneedformanualdefrosting,pushtheECObuttonformorethan2secondanda
manualdefrostwillstart. After30min.theelectroniccontrolwillreturntonormalmode.
