1
Right Rong
2. Mounting sequence of screws
Mount the screws diagonally in order of
number
Teching Craftsman®
Basic knowledge on standard parts assembly
1. Mounting of screws 3. Mounting of snap ring
Right
Rong
Push in the snap ring in
parallel.
Push in the snap
ring obliquely.
4. Lubricant mark
Where this mark is shown, it is recommended to apply
create to improve mechanical performance.
