SENSOR INFORMATION:
TEST:
✔ Slide the LUX switch
toSUNposition(belowisSUN).Slide
theSENSswitch
tomaximum(belowisthemaximum).Adjust
theTIMEswitch,slide5”switchtoONposition.(slideupwards).
✔Switchonthepower;thesensoranditsconnectedlampwillhave
nosignalatthebeginning.AfterWarm-up30sec,thesensorcan
startwork.Ifthesensorreceivestheinductionsignal,thelamp
willturnon.Whilethereisnoanotherinductionsignalanymore,
the load should stop working within 5sec and the lamp would
turn off.
✔SlidetheLUXknobaboveontheminimum(moon).Iftheambient
light is more than 10LUX, the sensor would not work and the
lamp stop working too. If the ambient light is less than 3LUX
(darkness), the sensor would work. Under no induction signal
condition,thesensorshouldstopworkingwithin5sec.
NIGHT:motionsensoronlyworksbynight
ON:Motionsensorworksbydayandnight
SENS:Adjuststhesensitivityofthemotionsensor
Time delay: Sets lighting time after activity between 5/30s or
1/3/5/8min.
Note:whentestingindaylight,pleaseturnLUXswitchto
(SUN)
position,otherwisethesensorlampcouldnotwork!Ifthelampis
morethan60W,thedistancebetweenlampandsensorshouldbe
60cmatleast.
Motionsensorworksby dayand night.For daylightuse,setLUX
knobtomaximum(SUN)forcorrectwork.
SOME PROBLEM AND SOLVED WAY
✔ The product does not work:
a.Please check if the connection of power source and load is
correct.
b.Pleasecheckfunctionofthelampandswitchonmainfuseafter
complete installation.
c.Please check if the settings of working light correspond to
ambientlight.
✔ The sensitivity is poor:
a.Pleaseremoveobjectsoutfromthedetectionarea.
b.Pleasecheckiftheambienttemperatureistoohigh.
c.Please check if the induction signal source is in the detection
field.
d.Pleasecheckiftheinstallationheightcorrespondstotheheight
required in the instruction.
✔ The lighting time is not compliance with needed:
a.If the sensor can’t shut off the lamp, please check if the time
delayissettomaximumposition
b.Pleaseadjustthelightingtimeasyouneed.
WARRANTY
No guarantee or liability can be accepted for any changes and
modifications of the product or damage caused due to incorrect
use of this product.
CONNECTION
•Switchoffthemainfuse.
•Checkwithavoltagetestertobesurealllinesarereallystress-
free.
• Installthesensortowallorceilingusingtheinstallationmaterial
includedintothepackage(seebelowtheinstallationdiagram).At
this,attendtothecablelocationanditsalignment.Alsoattendto
thedetectionareaandmaxdistance.
•Connect the power and the load according to the connection-
wirediagrambelow.
Heightofinstallation:2.2-4m DetectionDistance:Max.6m
Testthesensorasbelow.
CONNECTION-WIRE DIAGRAM:
WiththeCEsign,Techly
®
ensures that the product is conformed to
thebasicEuropeanstandardsanddirectives.
In accordance with the WEEE regulation, electrical and
electronicequipmentmustnotbedisposedofwithhousehold
waste. It means that used electrical and electronic products
shouldnotbemixedwithgeneralhouseholdwaste.Thereisa
separate collections system for these products.
EN - 2
WWW.TECHLY.COM
INFRARED MOTION
SENSOR
