Model: TX-203,TX-204,TX-228; Article No. 5021,5023,5040; 10/2022
Max. number of panels
1
2
Panel connection
MC4
MPPT voltage range (V)
29-48
Starting voltage (V)
22
Operating voltage range (V)
16-60
Max. input voltage (V)
60
Max. input current (A)
11.5
2x 11.5
Max. input short-circuit current (A)
15
2x15
AC-output
Rated output power (VA)
300
600
Rated output current (A)
1.36 at 220V
1.30 at 230V
1.25 at 240V
2.73 at 220V
2.61 at 230V
2.50 at 240V
Rated output voltage/range (V)
220/180-275
230/180-275
240/180-275
Rated frequency/rated frequency range
(Hz)
45-55 (under 50Hz @ 220 V & 230 V)
55-65 (under 60Hz @ 220 V & 230 V)
Power factor
>0.99 standard
0.8 leading......0.8 delayed
Output current harmonic distortion
≤3%
Maximum number of devices in series
12
6
Efficiency, safety and protection
Peak efficiency
96.70%
CEC weighted efficiency
96.50%
MPPT rated efficiency
99.80%
Nightly power consumption (mW)
<50
Mechanical data
Ambient temperature range (°C)
-40~+65
Storage temperature range (°C)
-40~+85
Dimensions (WxHxD) mm
182x164x29.5
250×170×28
Weight (kg)
1.98
3.00
Protection class
NEMA outdoor (IP67)
Cooling
Natural circulating air - no fans
AC output cable length (cm)
98
188
AC input cable length (cm)
10
8.5
Characteristics
Compliance
VDE-AR-N 4105:2018, EN50549-1:2019,
VFR2019, IEC/EN 62109-1/-2, IEC/EN
61000-3-2/-3, IEC/EN-61000-6-1/-2/-3/-4
