1
KM4
KM4 TT
KM4/DOS DOS
Teile
OnderdelenParts
01. Lid
02. Hopper
03. Push button switch
04. Grinder chamber
05. Sieve
06. Cutter blade
07. Receptacle
08. Tablestand
09. Dispenser
10. Operation handle
11. Dispens opening
01. Deksel
02. Bonenreservoir
03. Drukknop
04. Maalbeker
05. Zeef
06. Slagmes
07. Opvangbeker
08. Standaard
09. Doseerreservoir
10. Doseerschuif
11. Doseropening
English
Nederlands
Deutsch
01. Deckel
02. Bohnenbehälter
03. Schalter
04. Mahlgehäuse
05. Sieb
06. Schlagmesser
07. Auffanbehälter
08. Tischständer
09. Dosierbehälter
10. Bedienungsgriff
11. Doseröffnung
Find a place close to a plug-connection
and leave sufcient space over grinder or
dosing unit (about 20 cm) to enable lling
of the reservoir.
Slide bearer off appliance by pushing this
downwards.
Plugs and screws have been enclosed for
xation.
Before screwing bearer against wall drill 6
mm. holes in the wall (1 on top/2 below)
with a masonry drill and then put plugs in
holes. When xing on a tiled wall holes can
be drilled best in the joints.
The upward sides of bearer should be
pointing towards yourself, like the edged
part below which ts into the reservoir.
Slide appliance back into bearer.
Fixation to the wall (KM4, KM4/DOS and DOS)
