Technics SC-C70MK2 Basic Operating Instructions

09
  




11 Bass reflex port
12 Product identification marking
• The model number is indicated.
13 AC IN terminal (
)
( 11)
14 AUX IN terminal
• You can connect a portable audio player,
etc. with an analogue audio cable (not
supplied) and play back music.
15 Optical digital input terminal
• You can connect a DVD player, etc. with
optical digital audio cable (not supplied)
and play back music.
• The digital audio input terminal of this unit
can only detect the following linear PCM
signals. For details, refer to the operating
instructions of the connected device.
- Sampling frequency:
32/44.1/48/88.2/96 kHz
- Number of quantisation bits:
16/24 bit
16 USB-A terminal
DC 5 V 500 mA
• You can connect a USB device to the unit
and play back music stored on the USB
device.
• This unit does not guarantee connection
with all USB devices.
A more detailed operating instruction is
available in “Operating Instructions” (PDF
format).
www.technics.com/support/
• Depending on a thickness of USB device,
you may not connect USB device while LAN
cable is connected.
This unit (rear)
17 LAN terminal
( 13)
18 DAB ANT / FM ANT terminal
( 11, 17)
10 Subwoofer
(Bottom)
• Do not install this unit
on the rough surface.
Doing so may cause
the subwoofer to be
damaged.
• Do not hold the
subwoofer when
carrying this unit.

Technics SC-C70MK2 Specifications

General

Type	Home audio mini system
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Card reader integrated	-
Audio formats supported	AIFF, ALAC, DSD, FLAC, MP3, WAV
Digital audio optical in	1
Supported radio bands	DAB, FM
Subwoofer type	Active subwoofer
RMS rated power	30 W
Woofer diameter	80 mm
Tweeter diameter	20 mm
Number of speakers	2

Weight and Dimensions

Depth	280 mm
Width	450 mm
Height	143 mm
Weight	8000 g
