Frequency .r_ponse (Dolby NR Off) :
TYPE I (NORMAL) " " "
TYPE ]1 (HIGH POSITION)
TYPE 1V(METAL)
40 Hz-14 kH.z, -+.3dB
20 Hz-17 kHz
40 Hz-14 kHz, .+.3dB
20 Hz-17 kHz
40 Hz-15 kHz, _ dB
20 Hz-18 kHz
S/N (signal level:max recording level, HIGH POSITION type
tape)
NR off 54 dB (A weighted)
Dolby B NR on 64 dB (A weighted)
Input sensitivity and Impedance
REC (IN) 320 mV/47 kt2
Output voltage and impedance
PLAY (OUT) 320 mV/500 Q
• GENERAL
Power supply
Power consumption
Dimensions (WX HX D)
Weight
AC 120 V, 60 Hz
18W
430X 131X286 nun
(16-15/16" XS-5/3T' X 11-1/4")
3.8 kg (8.5 lb.)
Note:
Specifications are subject to change without notice.
Weight and dimensions are approximate.
• EQUALIZER SECTION
Frequency response
(center position)
Maximum output voltage
Rated output voltage
Maxlmum input voltage
Input sensitivity
Total harmonlc distortion
Signal-to-noise ratio
Input Impedance
Gain
Equalization-level controls
Centerfrequencies
5 Hz-100 kHz (-3 dB)
8 V (1 kHz, THD 0.03%)
1V
8V (1 kHz)
1V
0.005% (20 Hz-20 kHz), at 1 V output
0.003% (1 kHz), at 1 V output
105 dB/1 V, IHF' A
.......... 47k_
0±1 dB
+12 dB to-12 dB
(7 frequency ranges, in 2 dB steps)
63 Hz, 160 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 12.5 kHz
! GENERAL
Powersupply
Powerconsumption
Dimensions (WX HX D)
Weight
AC 120 V, 60 I-Iz
I1W
430X97X280 mm
(16-15/16"X3-13/1/6" X11-1/32")
2.9 kg (6.4 lb.)
• AUDIO
No. of channels
Frequency response
Output voltage
Oynamic range
S/N
Total harmonic distortion
Wow and flutter
DA converter
Output Impedance
Load Impedance
• PICKUP
Wavelength
• GENERAL
Powersupply
Powerconsumption
Dimensions ONX HX D)
Weight
I MASH is a trademark of NTT. }
2 (left and right, stereo)
2-20,000 Hz, ±1 dB
2 V (at 0 dB)
92 dB
103 dB
0.007% (1 kHz, 0 dB)
Below measurable limit
MASH (1 bit)
Approx.1 k_
More than 10 k.Q
780 nm
AC 120 V, 60 Hz
llW
430X170X387 mm
(16-15/16'" X6-11/16"X15-1/4")
7.0 kg (15.4 lb.)
Notes:
1. Specifications are subject to change without notice.
dimensions are approximate.Weight and " " '
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
• EQUALIZER SECTION
Frequency response (center position)
Maximum output voltage
Output voltage
Total harmonic distortion
Input sensitivity
S/N
Maximum input voltage
Input impedance
Gain
Band level controls
5 Hz-100 kHz, -3 dB
6V(1 kHz)
1V
0.007% (20 Hz-20 kHz)
0.OO5%(1 kHz)
1V
110 dB (IHF 'A)
6V
33k_
0±1 dB
+12 to -12 dB
(7 continuously variable elements per channel)
Center frequencies
63Hz, 160 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, 16kHz
Note:
Specifications are subject to change without notice.
Weight and dimensions are approximate.
• GENERAL
Power supply
Power cons0mption
Dimensions(WX HX D)
Weight
AC 120 V, 60 Hz
8.5 W
430X75X192.5 mm
(16-29/32" X 2-15_6" _r_19/32"')
- 1.8 kg_.95 lb.)
Notes:
1. Specifications are subject to change without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is m_sured by the digital spectrum
• analyzer.
