Technics SX-KN6500

*ACHTUNG:Die lasereinheit nicht zerlegen.Die lasereinheit darf nur gegen einc vom hersteller
spezifizierte einheit ausgetauscht werden.
*Capacity values are in microfarads (uF) unless specified otherwise, P=Pico-farads (pF) F=Farads
(F) / *Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000K
(OHM)
*The marking <RTL> indicates that the Retention Time is limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for a
specific period of time. The retentionperiod of availability is dependant on the type of assembly ,
and in accordance with the laws governing part and product retention. After the end of this
period, the assembly will no longer be available.
*Since SW consists of buttons and P.C.B.’s, we do not supply it as an individual part (refer to “22.
Manual Keyboard Parts and Control Panel Parts Location”.).
*[SPC] in Remarks columns parts that are supplied by SPC..
*[M] in Remarks columns parts that are supplied by MESA.
*“<IA>”-“<IH>”, marks in Remarks indicate languages of instruction manuals. [<IA> : Danish, <IB>
: English, <IC> : AmericanEnglish, <ID> : French, <IE> : Germany, <IF> : Italian, <IG> : Spanish,
<IH> : Netherlands]
Ref. No. Part No. Part Name & Description Pcs Remarks
1 QGQG0006AB PUNCHING NET(L) 1 [M]
2 QGQG0007AB PUNCHING NET(R) 1 [M]
3 QGQG0008AB PUNCHING NET(C) 1 [M]
4 RFKGXKN6500P CONTROL PANEL ASS'Y 1 [M]
5 QYAG3009AA MUSIC STAND ASS'Y 1 [SPC]
6 QYKG284AA BOTTOM CASE ASS'Y 1 [M]
7 QMRG5159AAK SPEAKER PACKING 4 [SPC]
8 QMRG5160AAK SPEAKER PACKING 8 [SPC]
9 QMFG4254AA CUSHION 4 [SPC]
10 QMFG4253AA CUSHION 2 [SPC]
11 SHGG3130A FOOT 4 [SPC]
12 QMFG4080AAK CUSHION 13 [SPC]
13 QEUGUZW15E FFC(33P) 3 [M]
14 QHDG025AA SCREW 2 [SPC]
15 QHDG050AA SCREW 8 [SPC]
16 XYE3+FG12 SCREW 24 [SPC]
17 XTW3+10QFZ SCREW 4 [SPC]
18 XTW3+12Q SCREW 44 [SPC]
19 XTW3+16JFZ SCREW 17 [SPC]
20 XTV3+12G SCREW 44 [SPC]
21 K2AA2G000003 AC IN COVER 1
(EH,X,XD,XT)[SPC]
21 K2AA2G000003 AC IN COVER 1
(EX,EZ,EB,EG)[SPC]
21 SJS9334A AC IN COVER 1
(P,PC)[SPC]
21 K2AA2G000003 AC IN COVER 1
(XS,XA,GN)[SPC]
22 XTB3+12GFZ SCREW 2 [SPC]
23 XTT4+16GFZ SCREW 6 [SPC]
24 XTW3+20Q SCREW 2 [SPC]
25 XYN4+F20 SCREW 4 (P,PC,X,XS,XD,XT,XA)[SPC]
25 XYN4+F25 SCREW 4 (EX,EZ,EB,EG,EH,GN)[SPC]
26 QMFG4252AA CUSHION 6 [SPC]
