MAINTENANCE
Prior to any maintenance work or changing
parts, disconnect the appliance from the gas
and electricity power sources. Servicing must
only be carried out by authorised personnel.
REPLACING THE TAPS
Proceed in the following way when replacing a tap:
• Remove pan supports, burner heads.
• Unscrew the burner xing screws (Vc) (g. 24).(four
for ultrarapid burner and two for the other burners)
• Remove the hob, unscrewing frontal and rear
xing screws (Vs) (g. 24) which lock the hob at
the supports (S).
• Pull out the knobs.
• Unscrew the nuts (D) of the gas aluminium pipes
and pull out the thermocouple quick connectors (F)
(g. 26).
• Unscrew the screws (Vt) (g. 25) which lock the
crosspieces.l
• Unscrew the screws (Vb) (g. 25) which unite the
the bridles of the taps to the front frame.
• Make to slip the ramp toward the back part and
unscrew the screws (Vb) (g. 26) in order to free the
taps.
• Change seal each time a tap is replaced. This will
ensure perfect retention between the tap and part.
• Reassemble all the parts following the same
procedure but in the reverse order.
