TechniSat DIGITRADIO Car 2 User Manual

60
4.6 Positioning the microphone
1. If possible, insert the cable in the roof lining, but make sure that the microphone remains close to the driver. As an
alternative, you can also mount the microphone at the top edge of the windscreen using self-adhesive pads.
2. Fix the microphone in a suitable position, such as the roof lining or the driver’s sun visor.
4.7 Connecting the reception unit to the power supply
1. Position the cable for the power supply to the reception unit (USB connection) in such a way that it can reach the power
connection on the vehicle (e.g. the 12 V cigaree lighter).
2. If possible, place the cable under the side cladding on the windscreen. As an alternative, you can also mount the cable
on the windscreen and the dashboard with self-adhesive pads.

TechniSat DIGITRADIO Car 2 Specifications

General

Dimmable	Yes
Projection	No
Product color	Black
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FRE, ITA, NOR
Radio type	Car
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	20
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Apple docking compatibility	Not supported
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Display type	LCD
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	3.7 V
Battery capacity	800 mAh
Compatible battery sizes	AAA
Number of batteries supported	2
Power source	Cigar lighter
Package depth	63 mm
Package width	157 mm
Package height	308 mm
Package weight	550 g
RMS rated power	- W

Weight and Dimensions

Depth	31 mm
Width	76 mm
Height	60 mm
Weight	64 g
