Display resolution: according to the scale used: hrs., min., sec.,
cents
Overall accuracy:
+/- 0,1 % fs
Counting autonomy in case of power failure
: depending on battery
capacity (ex. with a 400 mAh full charge battery the autonomy is 44
hrs. approx)
Inputs delay:
15 m sec. Max.
Display:
4 Digit Red h 12 mm
Compliance:
ECC directive EMC 2004/108/CE (EN 61326), ECC
directive LV 2006/95/CE (EN 61010-1)
7.5 – INSTRUMENT CODE
TT 34 a b c d ee
a :
POWER SUPPLY
F = 12 VAC/VDC
A = 24 VAC
C = 115 VAC
D = 230 VAC
b : INPUTS
C = Free voltage contacts
V = Voltage signals (the same voltage supply value).
c : OUTPUT OUT1
R = Relay
O = 12 VDC for SSR
d : OUTPUT OUT2
R = Relay
O = 12 VDC for SSR
- = None
ee = SPECIAL CODES
