To refit the door with the hinges on the opposite side, proceed
as follows:
1. remove the cover plugs from the doors, revealing the fixing
holes for the handles;
2. refit the refrigerator and freezer handles on the right hand
side of the doors (fig. B);
3. unscrew the pin of the top right hand hinge using a 5 mm
socket wrench and refit it on the left hinge (fig. C);
4. reposition the refrigerator door and screw down the midd-
le hinge on the left hand side, turned 180° (fig. D), being
careful not to overtighten the screws;
5. reposition the freezer door and screw down the bottom
hinge on the left hand side, after moving the pin to the left
hand hole;
6. remove the cover plugs from the left hand side of the cen-
tral crosspiece and position them on the right (fig. E);
7. refit the bottom plinth;
8. to align the doors precisely, adjust the middle hinge,
moving it horizontally; once the doors are perfectly ali-
gned, fully tighten the screws.
Attention: once you have finished inverting the doors, check
that the door seals adhere to the cabinet properly. If they do
not, heat the loose section of door seal with a standard
hairdryer, taking care not to burn it.
