Installation noise protection board
By installing this board, the noise of the washing machine can be reduced.
1.
Remove the adhesive from the back side of the felt and paste the felt onto the back
side of the protection board in a symmetrical position to the board’s corners.
Lean (push) the machine backwards and unscrew the four feet.
Remark: not lean or push the machine towards it’s front !
2. Adjust the board in the way to align the four holes with the four screw fixing holes,
felt at back side of the board.
3. Install the four feets and fix the board to the cabinet, then fix the machine in desired
position
fig.5
fig.1
