Field or control Description
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
T
rigger
Sets the current oscilloscope trigger settings to match the search criteria.
RS-232 serial bus search configuration menu
Use the RS-232 Search configuration menu to define conditions to search for and mark on an RS-232 bus waveform. Y
ou can have
multiple searches on the same bus.
Note: Requires option SRCOMP
.
Field or control Description
Display Enables or disables displaying search marks on this search.
Source Select the RS-232 bus that you want to search.
Mark On Select the type of information for which to search.
Data Bytes Sets the number of data bytes (1 byte = 8 bits) for which to search (one to ten bytes). Use the A knob
to change the value.
Only available when Mark On = Tx Data or Rx Data.
Data Sets the data pattern for which to search. The number of bits shown depends on the Data Bytes
setting.
T
ap the Binary or Hex field and use the A and B knobs to select and change the values. Or double-tap
on the field and use the virtual keypad to enter values.
Only available when Mark On = Tx Data or Rx Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Or double-tap the field and use the virtual keypad to enter the data. See Binary, decimal, hex, and
octal virtual keypads on page 228.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings. If the trigger settings are not
valid in Search, this control is either not available or grayed out.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
SPI serial bus search configuration menu
Use the SPI Search configuration menu to define conditions to search for and mark on an SPI bus waveform.
Note: Requires option SREMBD.
Menus and dialog boxes
3 Series Mixed Domain Oscilloscope Printable Help 149
