Oscilloscope Reference Hits in Box

Hits in Box

Displays the number of points in or on the histogram box.

Mean±1 StdDev

The percentage of points in the histogram that are within one standard deviation o f the histogram mean.

Mean±2 StdDev

The percentage of points in the histogram that are within two standard deviations of the histogram mean.

Mean±3 StdDev

The percentage of points in the histogram that are within three standard deviations of the histogram mean.

Peak Hits

Displays the number of points in the largest bin of the histogram.

Pk-Pk

Displays the peak-to-peak value of the histogram.

Vertical histograms

display the "voltage" of the highest nonzero bin minus the "voltage" of the lowest

nonzero bin.

Horizontal histogr

ams display the "time" of the right-most nonzero bin minus the "time" of the

left-most nonzero bin.
