Oscilloscope Reference Peak to peak
Peak to peak
This voltage measurement is the absolute difference between the maximum and minimum amplitude in
the entire waveform or gated region.
Period
This measurement is the time re quired to complete the first cycle in a waveform or gated region. Period is
the reciprocal of frequency and is measured in seconds.
Phase
This timing measurement is the amount of time that one waveform leads or lags another waveform. The
measurement is expressed in degrees where 360° comprise one wavef orm cycle.
Select trigger polarity
Select the polarity from the drop-down list.
Click Positive to trigger on a positive-going pulse.
Click Negative to trigger on a negative-going pulse.
Click Either to trigger the instrument on either polarity.
