Appendix G: Application Module-enabled Commands
Application Mo
dule
Commands
DPO4COMP,
MDO3COMP
Computer Serial Triggering and Analysis Module. Enables triggering on packet-level information on
RS-232/422/485/UART buses as well as analytical tools such as digital views of the signal, bus views,
packet decodi
ng, search tools, and packet decode tables with time-stamp information.
BUS:B<x>:RS
232C:BITRate
BUS:B<x>:RS232C:DATABits
BUS:B<x>:RS232C:DELIMiter
BUS:B<x>:R
S232C:DISplaymode
BUS:B<x>:RS232C:PARity
BUS:B<x>:RS232C:POLarity
BUS:B<x>:
RS232C:RX:SOUrce
BUS:B<x>:RS232C:TX:SOUrce
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:RS232C:CONDition
SEARCH:S
EARCH<x>:TRIGger:A:BUS:B<x>:RS232C:RX:DATa:SIZe
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:RS232C:RX:DATa:VALue
SEARCH:SEARCH<x>:TRIGger:A:BUS:B<x>:RS232C:TX:DATa:SIZe
SEARCH:S
EARCH<x>:TRIGger:A:BUS:B<x>:RS232C:TX:DATa:VALue
TRIGger:A:BUS:B<x>:RS232C:CONDition
TRIGger:A:BUS:B<x>:RS232C:RX:DATa :SIZe
TRIGger
:A:BUS:B<x>:RS232C:RX:DATa:VALue
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:SIZe
TRIGger:A:BUS:B<x>:RS232C:TX:DATa:VALue
G-8 MDO4000/B/C, MSO/DPO4000B and MDO3000 Series Oscilloscopes Programmer Manual
