Tektronix TG8000 Service Manual

AWVG7 module replaceable parts list
AWVG7 module r
eplaceable parts list
This section
contains a list of the replaceable modules for the AWVG7 module.
Use this list to identify and order replacement parts. For parts ordering or
servicing information, see Parts ordering information or Module servicing in the
Mainframe replaceable parts list section of this manual. (See page 2-35.)
Abbreviations
Abbreviations conform to American National Standard A NSI Y1.1-1972.
Replaceable parts
The following tables list the replaceable parts for the AWVG7 module.
Table 7-4: AWVG7 module – replaceable parts
Fig. &
index
number
Tektronix
part number
Serial no.
effective
Serial no.
discont'd Qty Name & description
7-10- 116-A018-05 1
EXCHANGE MODULE: AWVG7
7-10-1 441-A269-02 1
CHASSIS, MODULE
-2 333-A454-00 1
PANEL, REAR, AL, AWVG7
-3 214-4762-00 2
SPRING, CONICAL
-4 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM,
HEAD HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-5
348-A128-00
2.5CM SHLD GASKET, ELEK: FINGER TYPE, 5.1MM LX6.4MM W, BE-CU [97-645-02]
-6 174-B851-00 6
CABLE ASSY, RF: 75 OHM COAX (RG179), 5.5CM L, BNC TO MCX
-7
211-A245-01
5
SCREW, MACHINE: M3X6MM L, PNH, STL, NI PL, CROSS REC,
W/KOGATAMARU & LOCK WASHER
-8 334-1378-03 1
MARKER, IDENT: MKD SERIAL NO.
STANDARD ACCESSORIES
075-1045-XX 1
MANUAL, TECH: MODULE INSTALLATION INSTRUCTIONS
063-4440-XX 1
DVD, SOFTWARE LIBRARY & DOCUMENTATION
OPTIONAL ACCESSORIES
003-A041-00 1
NUTDRIVER, BOX: 14 MM HEX, BNC RETAINING NUT, MODIFIED 19 MM
TG8000 Multiformat Test Signal Generator Service Manual 7–19
