Mainframe replaceable parts list
Table 2-10: Pow
er Supply a ssembly replaceable p arts
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd Qty Name & description
2-18- 650-5544-00 1
POWER SUPPLY ASSY, TG8000
Subparts
-1 441-2706-00 1
CHASSIS, POWER SUPPLY, ASSY TG8000, SAFETY CONTROLLED
-2 211-A245-01 11
SCREW, MACHINE; M3 X 6 MM L, PNH, STL, NI PL, CROSS REC, W /NUT & LOCK
WASHER
-3 878-0685-00 1
CIRCUIT BOARD ASSY; POWER ADAPTER BOARD, UNTESTED
-4 119-B054-00 1
POWER SUPPLY; INPUT 85-264 VAC, OUTPUT 5VDC, 20A; SAFETY CONTROLLED
-5
337-4579-00 1
SHIELD, INSULATOR, POWER SUPPLY TG8000, SAFETY CONTROLLED
-6 174-B788-00 1
CA ASSY, SP, ELEC; 8, 18 AWG, 10.0 CM L, 2-N; SAFETY CONTROLLED
-7
211-1194-01 3
SCREW, MACHINE; M3 X 6MM, FLH BLACK, CROSS REC
-8 200-5249-00 1
COVER, TOP, POWER SUPPLLY, SAFETY CONTROLLED
-9 131-6643-00 1
CONTACT, ELEC; GROUNDING, 0.169 L, 0.320 DEEP, ELECTROLESS NICKEL;
TDS3012
-10 878-0651-00 1
CIRCUIT BOARD ASSY; FAN, UNTESTED
-11 407-5696-00 1
BRACKET, EMI CLIP, FAN MOUNT
-12 211-0553-00 2
SCREW, MACHINE; 6-32 X 1.5, PNH, TORX T15, ZINC PLATED STEEL
-13 119-7932-00 1
FAN ASSEMBLY (12V, 13.4 CFM) 40 X 40 X 28 MM, TERMINATED, SAFETY
CONTROLLED
-14 333-4682-00 1
REAR PANEL POWER SUPPLY, SAFETY CONTROLLED
-15 211-1266-01 2
SCREW, METRIC 4-1.4 X 12MM, FAN, FLATHEAD, STL, ZINC PLATE, PHILLIPS
-16 367-0530-00 1
HANDLE, BOW; AL, 1.0 X 1.25, STAIN FINISH, SAFETY CONTROLLED
-17 119-7929-00 1
FILTER, EMI; AC LINE FILTER; 4.0A, 115-250 VAC, 50/60 HZ, IEC INPUT, LOCKING
CORD, FAST-ON/SOLDER LUG OUTPUT, SNAP-IN CHASSIS MOUNT, SAFETY
CONTROLLED
-18 211-0911-00 2
SCREW, MACHINE; M2.5, PITCH 0.45MM, LENGTH 11MM, HEAD DIA 5MM, HEAD
HEIGHT 2MM, BRIGHT NICKEL FINISH STEEL, SLOTTED PHILLIPS
-19 214-4762-00 2
SPRING, CONICAL
-20 174-6276-00 1
CABLE, ASSEMBLY LINE FILTER, TG8000, SAFETY CONTROLLED
-21 212-A041-01 1
SCREW,MACHINE;M4X8MML,PNH,STL,NIPL,CROSSREC,W/NUT&LOCK
WASHER
-22 174-6151-01 1
CABLE ASSEMBLY (LINE FILTER TO GROUND 16 AWG), SAFETY CONTROLLED
-23 174-6138-00 1
CABLE ASSY, 2 X 5 FEMALE TO FEMALE, KEYED
-24 174-6277-00 1
CAT5E CABLE ASSEMBLY, RJ45, MALE/MALE 12.500 IN. L, SAFETY CONTROLLED
2–42 TG8000 Multiformat Test Signal Generator Service Manual
