BG7 Black Generator module
BG7 module
TIMECODE submenu
(GPS7 module only)
Use this submen
u to set timecode parameters for the selected output. This menu is
present only if GPS7 module is installed.
NOTE. To display the TIMECODE submenu, the BG7 module hardware must be
version 1.2 or above and the mainframe must have software version 5.1 or above
installed.
This submenu is available only w hen NTSC, NTSC No Setup, or PAL is the
selected signal format. This submenu is not available when the selected signal
format is HD SYNC.
Use the up
(▲) or down (▼) arrow button to change the menu items. The
following figure shows the TIMECODE submenu.
Figure 3 -39: BG7 module TIMECODE submenu
TG8000 Multiformat Test Signal Generator User Manual 3–71
