Release Notes
1080 50p, 1080 59.94p, and
1080 60p Formats
In these format
s, audio phase display is not displayed if there are two or more
trace displays in other tiles.
ANC data displ
ay reports the incorrect line number for these formats.
SDI PixMon out is intended for viewing Picture information only. In these
formats, Pi
xMon out provides a “combined” picture and the ANC and
embedded audio data ma y be missing.
Incompatible Operation
When applying SD or HD signals to any monitor that does not support them, the
unit indic
ates that the signal input is not standard. Applying unsupported video
signals may result in a frozen PICT display.
OP47 Teletext
The OP47 Protocol Error alarm may not trigger accurately. To avoid getting this
error, d
isable the alarm in CONFIG > Alarms > Closed Captions/Teletext.
Print
You can print the error log for single input mode, but not simultaneous input mode.
SDI Status Display
When the input signal is missing, the Cable Length meter, the Cable Length
readout, and the Cable Loss readout on the SDI Status display indicate zero. Use
the Input Status on the Status Bar for the actual signal state.
Simultaneous Input Mode
(Option SIM)
To access Analog Output Mapping and AES Output Mapping settings while
in simultaneous input mode, go to CONFIG > Audio Inputs/Outputs > Dual
Audio > Audio Inputs.
The phase pair selected as an audio source is for the channel of the phase
pair you changed last.
External Reference reports unlocked if no SDI A signal is on Channel 1.
Selecting AES B as a source when it is an output causes a blank tile.
Phase pair and headphone selections for downmix are in red text and are
labeled 9-10 i nstead of Lt-Rt.
Only single input logs can be printed.
You might see data that you do not need to see if you are viewing data types in
the Anc Data Inspector display with Watchlist enabled while in simultaneous
input mode (SIM).
Waveform Monitors Release Notes 5
