Telefunken 40FAG8030 - Page 5

English - 5 -
Holes and measurements for the wall mount bracket installation;
A VESA WALL MOUNT MEASUREMENTS
B
,ŽůĞWĂƩĞƌŶ
Sizes (mm)
WH
100 100
C ^ĐƌĞǁ^ŝnjĞƐ
FG
D >ĞŶŐƚŚ;yͿ
min. (mm) 7 5
max. (mm) 10 6
E dŚƌĞĂĚ;zͿ M4
Antenna Connection
Connect the aerial or cable TV plug to the aerial input (ANT) socket or satellite plug to the satellite input (LNB) socket located on the rear side of the TV. Rear side of the TV
$17
/1%
If you want to connect a device to the TV, make VXUHWKDWERWKWKH79DQGWKHGHYLFHDUHWXUQHGRႇ before making any connection. After the connection is done, you can turn on the units and use them.
English - 6 -
Other Connections
,I\RXZDQWWRFRQQHFWDGHYLFHWRWKH79PDNHVXUHWKDWERWKWKH79DQGWKHGHYLFHDUHWXUQHGRႇEHIRUHPDNLQJ any connection. After the connection is done, you can turn on the units and use them.
Connector Type Cables Device
HDMI
Connection
(back&side)
SPDIF
SPDIF
(Coaxial Out)
Connection
(
side)
Side AV
Side AV
(Audio/
Video)
Connection
(side)
Audio/Video
Cable
Side Audio/Video
Connection Cable
HEADPHONE
Headphone
Connection
(side)
USB
Connection
(side)
CI
Connection
(side)
CAM
module
LAN
Ethernet
Connection
(back)
LAN / Ethernet Cable
When using the wall mounting kit (contact your dealer to purchase one, if not supplied), we recommend that you plug all your cables into the back of the TV before mounting on the wall. Insert or remove the CI module only when the TV is SWITCHED OFF. You should refer to the module instruction manual for details of the settings. The USB inputs on the TV support devices up to 500mA. Connecting devices that have current value above 500mA may damage your TV. When connecting equip- ment using a HDMI cable to your 79WRJXDUDQWHHVX௻FLHQWLPPXQLW\ against parasitic frequency radiation and trouble-free transmission of high GH¿QLWLRQ VLJQDOV \RX KDYH WR XVH a high speed shielded (high grade) HDMI cable with ferrites.
