Telefunken Dynamic Series - Page 4

Low Prole (-SH) Wireless (-WH)
The smaller footprint of the M80-SH & M81-SH make them ideal for
tight t applications including drums and guitar amps on stage, as well
as vocal positions for drummers and keyboard players, where a full size
microphone may be too obstructive. Both models are sonically identical
to their handheld versions. Both the M80-SH & M81-SH come with drum
mounts and a TELEFUNKEN right angle XLR cable.
M80-WH & M81-WH wireless capsule heads are designed to deliver the
same character and high SPL handling as their handheld versions, whether
it’s the M80’s natural, condenser-like response with a subtle high frequency
rise, or the M81’s smooth frequency response and exceptional midrange
articulation. They are compatible with the following industry standard
wireless transmitters: Shure® - Axient, UHF-R, QLXD, ULXD, ULX, PG,
PGX, SLX & UR2. Lectrosonics® - HH & HHa. Sony® - UTX-M03.
6 TELEFUNKEN Elektroakustik 7Dynamic Series
Technical Specications
Polar Pattern Supercardioid
Frequency Range 50 Hz – 18 kHz, ± 3dB
Capsule 25 mm, Dynamic Moving Coil
Transformer T80
Sensitivity 1.54 mV/Pa
Output Impedance 325 Ω
Maximum SPL (for 1% THD) 135 dB
Dimensions 125 mm x 48 mm
Weight 340 g
Technical Specications
Polar Pattern Supercardioid
Frequency Range 50 Hz – 18 kHz, ± 3dB
Capsule 25 mm, Dynamic Moving Coil
Transformer T80
Sensitivity 1.54 mV/Pa
Output Impedance 325 Ω
Maximum SPL (for 1% THD) 135 dB
Dimensions 95 mm x 48 mm
Weight 162 g
M80-SH M80-WH
