Item No. Description Quantity Req. Designator Remarks
46-10962W-02X PIN BASE *2 TJC2-2A 1 P801 FOR DEGAUSSING COIL
46-35184W-03X PIN BASE *3 TJC1-3A 1 P802 FOR POWER CORD
66-20516X-0B0 FUSE HOLDER 2 FOR F801
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR C827
67-339070-1E7 SPRING CLIP 1 FOR Q801
67-H28649-3A0 HEAT SINK 1 FOR Q801
11-SK2645-0AX TRANSISTOR 2SK2645-01MR (POWER 1 Q801
11-2SD882-0AX TRANSISTOR 2SD882-P (NPN) 1 Q805
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C835
26-APK102-ME4 CAP. CER 1000PF 400VAC+/-20% E 1 C835A
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D831
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D830
10-0FR104-FBX DIODE FR104 (FAST RECTIFIER) 1 D806
36-LIF010-AX0 LINE FILTER 1 T801
36-TRF020-AX2 TRANSFORMER CONV. BCK-4001-34d 1 T802
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R807
18-KE0105-JN3 RES. H.VOLT. CC 1M OHM 1/2W +/-5% 1 R802
27-AQT224-MVH CAP. M.PP 0.22 UF 250VAC 20% 1 C802
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% 1 C842
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% 1 FOR Q805(C) & GND
25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% 1 C816
35-139730-00X FERR. BEAD BF60 1 FOR Q801 "S"
50-02000D-1VS7 FUSE 250V/2A 1 F801
22-NTC479-XX0 NTC 4.7 OHM +/-18% NTC4.7D2-14 1 R801B
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 3 FOR RT801
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 6 FOR T802
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR D824
66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 2 FOR L804
25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% 1 C847A [(+) TO C846A]
26-AMK221-JZX CAP. CER 220pF 2KV +/-5% SL 1 C839
26-AMK331-JZX CAP. CER 330 pF 2KV +/-5% SL 1 C830
26-AMK561-JZX CAP. CER 560 pF 2KVDC +/-5% SL 1 C819
66-382330-0B7 RIVET 2.0X3.7X3.5 2 FOR P801
22-PTC200-XX0 POSISTOR 20 OHM (25-34) 1 RT801
08-D276SX-RCN ASS'Y - REAR CABINET 1
54-114000-00X FELT TAPE (150mmX19mmX0.3mm) 7 STICK ON REAR CAB.
55-D189RC-1CN REAR CABINET 1
58-D106SI-3UI INLAY SIDE AV 1
58-D192RI-8UI INLAY REAR AV 1
58-D276MP-JKT PLATE MODEL NO. 1
59-130460-00X RUBBER PAD (25mmX7mm) 2 STICK ON R. CAB.(FOOTING)
13
