Telefunken TK2129ST - Page 15

Item No. Description Quantity Req. Designator Remarks
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2 MTG PUSH BUTTON & F. CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 8 MTG SPK & FRONT CAB.
63-W30100-AB4 S/T SCREW W 3 X 10 AB 1 MTG LENS & F. CAB.
65-A60200-20E WASHER 6 X 20 X 2MM 4 MTG CRT & FRONT CAB.
67-X12668-0E0 SPRING CRT 6mmX40mmX0.5mm 1
67-X39732-0E2 POWER SPRING 1
08-D276SX-MAN ASS'Y - MAIN BD 1
07-457FF5-NX0 TUNER TEDH9 1 TU101
10-1N4001-EBX DIODE 1N4001 (RECTIFIER) 1 D301
10-1N4002-EBX DIODE 1N4002 (RECTIFIER) 1 D411
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D206
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D312
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D313
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D314
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D381
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D412
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D315
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D601
10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D452
10-79C3V9-DBX DIODE ZENER 3V9 1/2W 5% 1 D901
10-79C5V1-DBX DIODE ZENER 5V1 1/2W 5% 1 D004
10-79C5V6-DBX DIODE ZENER 5V6 1/2W 5% 1 D902
10-79C9V1-DBX DIODE ZENER 9V1 1/2W 5% 1 D404
11-DD1555-0AX TRANSISTOR 3DD1555 1 Q402
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q007
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q203
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q220
11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q601
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q006
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q005
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q004
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q205
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q902
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q904
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q906
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q920
11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q921
11-SC2482-0BX TRANSISTOR 2SC2482 1 Q401
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL) 1 Q101
13-000040-53P IC 4053 (ANALOG SW) 1 IC901
13-000040-66P IC 4066 (ANALOG SW.) 1 IC902
15
